ESD Floor Coatings | ESD Floor Paint

esd-dissipative-conductive-floor-coating-paint-esdproducts-bruno-depre

Anti static ESD floor paint: The two ESD-Paints E30 & A40
we offer are a range of Water Based ESD Floor Coatings

Electroguard A40® is a water based 1 Component
Acrylic Static Dissipative paint suitable for most requirements.
Electroguard E30® is a water based 2 Components
Polyurethane Static Dissipative Paint which offers greater durability for high traffic areas.

About ESD coatings or ESD flooring paints (Anti static paint) we can read the following
the international standard IEC/TR 61340-5-2
Protection of electronic devices from electrostatic phenomena – User guide.

4 ESD control program plan.

4.7.3 Static protective floor materials.

4.7.3.6.2.4 ESD-safe-Paints and coatings.

ESD Paints (Anti static paint) and epoxy coatings are applied to concrete floors in thin coats.
The primary advantages of these materials are their ease of application and coverage over a wide area.
They have a longer usable life than do floor finishes, but less than permanent ESD-floor materials.
Some materials are not applicable for clean rooms because they abrade or chip away.

4.7.3.7 Testing

The standard for testing the electrical resistance of ESD floor materials is IEC 61340-4-1.
The test method is designed to operate in the range of 1,0 x 10^3 to 1,0 x 10^10.
IEC 61340-5-1 requires that the maximum test voltage used for flooring systems used
as part of an ESD control program shall not exceed 100 V.
